2-Pack: SSUC206-20 Stainless Steel Insert Ball Bearings (1-1/4″)
Upgrade your machinery with this high-performance 2-pack of SSUC206-20 Insert Ball Bearings. Specifically designed for corrosive environments, these stainless steel bearings provide exceptional durability and resistance to rust and chemicals.
Featuring a wide inner ring and a set screw mounting method, these bearings are engineered to lock securely onto a 1-1/4″ shaft, ensuring stable operation even under heavy vibration or high-speed conditions.
Key Features
Corrosion Resistant: Crafted from premium stainless steel, making these ideal for food processing, chemical plants, and marine applications.
Spherical Outer Race: The spherical design allows the bearing to self-align within a housing, compensating for minor shaft misalignments.
Secure Mounting: Equipped with set screws to provide a firm, slip-free grip on the shaft.
Relubricatable Design: Features an integrated lubrication groove and holes, allowing for easy maintenance and extended service life through regular greasing.
Protection & Sealing: Outfitted with a single lip contact seal to keep contaminants out and retain essential lubrication inside the bearing.
Wide Inner Ring: Provides extra shaft support and better load distribution compared to standard narrow-ring bearings.
Technical Specifications
| Feature | Details |
| Model Number | SSUC206-20 |
| Quantity | 2 Bearings |
| Shaft Diameter (Bore) | 1-1/4 inch |
| Outside Diameter (OD) | 2.441 inch (62mm) |
| Length Thru Bore | 1-1/2 inch (38.1mm) |
| Outer Race Width | 0.748 inch (19mm) |
| Rolling Element | Ball Bearing |
| Mounting Type | Set Screw |
| Material | Stainless Steel |
Installation Tip
When installing, ensure the shaft is clean and free of burrs. Slide the bearing to the desired position and tighten the set screws alternately to ensure an even grip. For optimal performance in wash-down environments, ensure you use a food-grade or water-resistant grease during routine maintenance.
