Crestron HD-TX-201-C-2G-E-W-T: DM Lite 2×1 Auto-Switcher & Transmitter
The Crestron HD-TX-201-C-2G-E-W-T is a professional-grade wall plate transmitter and auto-switcher designed to extend high-definition signals over long distances. Finished in a White Textured style, this 2-gang device is the perfect solution for classrooms, conference rooms, and training centers that require a clean, integrated look with powerful signal switching capabilities.
It extends HDMI, VGA, and Analog Audio signals over a single CATx cable to a DM Lite or DMPS Lite receiver, supporting resolutions up to 4K UHD.
Key Features
Dual-Input Auto-Switching: Automatically detects and switches between HDMI and VGA inputs, ensuring the active presenter is always on screen.
4K UHD Extension: Delivers stunning video quality with support for 4K at 60Hz (4:2:0) or 4K at 30Hz (4:4:4).
Legacy Support: Includes a VGA input and a 3.5mm stereo jack for older laptops and analog audio sources, converting them for digital transmission.
LAN Pass-Through: Features a front-facing RJ-45 jack that passes through to the rear, providing a convenient network connection point for a laptop or computer.
Simple “One-Wire” Connection: Uses a single CAT5e (or better) cable to transmit video, audio, and power between the transmitter and receiver.
CEC Pass-Through: Allows for basic control of connected displays and devices without complex programming.
Technical Specifications
| Feature | Details |
| Model | HD-TX-201-C-2G-E-W-T (White Textured) |
| Max Resolution | 4096×2160 DCI 4K @ 24Hz / 3840×2160 4K UHD @ 60Hz (4:2:0) |
| Inputs | 1x HDMI (4K), 1x VGA (RGBHV/Component), 1x 3.5mm Analog Audio |
| Output | 1x DM Lite Link (RJ-45 Shielded) |
| Audio Formats | LPCM up to 8 channels, Dolby TrueHD, DTS-HD Master Audio |
| Compliance | HDCP 1.4, EDID Management, UL Listed |
| Mounting | 2-Gang U.S. Electrical Box (2-1/4″ deep min.) |
Mounting & Dimensions
Construction: Metal housing with white polycarbonate front label.
Dimensions: 4.19″ H x 3.50″ W x 2.07″ D.
Weight: 8.9 oz.
Faceplate Requirement: Specifically requires a Crestron FP-G2-DM-W-T faceplate (sold separately).
Powering Your System
This transmitter is highly flexible regarding power. If you pair it with a surface-mountable receiver (like the HD-RX-201-C-E), the receiver provides the power for both units. A separate 24VDC power pack is only required if pairing with another wall-plate style receiver.
